Trillium Flow Technologies updated DD pump range combines the engineering excellence, innovation, and heritage of our Gabbioneta Pumps® and Termomeccanica Pompe brands. Our expertise in designing and manufacturing BB1 pumps dates back to the 1960s, with thousands of units installed worldwide.

This BB1 style pump range is designed for the industrial and power markets and is available in many different configurations, from conventional foot mounted single stage, through to two stage and vertical configurations.

KEY FEATURES

Heavy-duty shaft to minimize rotor defection and maximize uptime
API 682 compliant seal chamber
Double suction Impeller
Foot mounted case configuration
Bearing housing leverages common parts across all Trillium Flow Technologies between bearings pumps
Bespoke high efficiency hydraulics

MAIN APPLICATIONS

Water transportation, supply & distribution
Sea water desalination
Crude oil pipeline
Tank farm transfer
Booster applications

OPTIONS

All API material options:
S-4,S-5,S-6,S-8,C-6,A-8,D-1,D-2, plus bespoke options
2 stage options for high head applications
Vertical configuration with product lubricated bearing available for select applications
High efficiency options with industry leading hydraulics
Composite wear parts, for improved efficiency and rotor dynamics
